Pylontech | SKU:
PYL-PELIO-L-2-10.24
Pylontech Pelio-L-5.12 LV x2 Battery Module 10.24kWh
£2,703.05
Unit price
/
Unavailable
Tax included
Shipping calculated at checkout.
Pylontech Pelio-L-5.12 LV x2 Battery Module 10.24kWh is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Delivery and Shipping
Delivery and Shipping
Next Business Day Delivery On Order placed Before 12:00 PM
Except Ireland, highlands and Islands.
Returns and Refunds
Returns and Refunds
- We have a 14-day return policy, which means you have 14 days after receiving your item to request a return.
- We will process your refund typically within 3-5 working days of receipt and assessment of returned goods.
- See our Returns and Refund policy for more detail -
Pylontech Pelio-L-5.12 LV x2 Battery Module 10.24kWh
£2,703.05
Unit price
/
Unavailable
This part is made up of the following items:
| 2 x nowrap="">Pylontech Pelio-L-5.12 LV Battery Module | A |
Pylontech Pelio-L-5.12 LV Battery Module
- Expandable modular design, up to A 20*5.12kWh in parallel (3-modules stack for A wall mounting A and 4-modules A stack for A ground mounting)
- High energy density cells makes for lightweight but high capacity batteries
- Smaller footprint and indoor/outdoor compatible to save your valuable space
- Secured by self-developed cells. modules and BMS
- Dual active protection mechanism enhances safety significantly
- Designed for 15+ years or >8000 charging cycles
- Compatible with A Solis low voltage hybrid/AC inverters (see attached document)
- Remote monitoring of the battery system via a plug-in wifi module (supplied with the installation kit, not with the battery itself)
Required: A target="_blank">PYL-PELIO-WALL-MOUNT A for 1 to 3 batteries (Wall-Mounted Installation Package) OR A target="_blank">PYL-PELIO-GROUND-MOUNT A for 1 to 4 batteries A (Ground-Mounted Installation Package)
If you have any technical queries about this product or wish to report any issues with the information on this page then please use the Form to contact us.
- Weight:
- 90 kg
- Rated Power:
- 10,240 W
- Battery Type:
- Lithium Ion
- Nominal Energy:
- 10240 Wh
- Depth of discharge:
- 95.00 %
- Voltage:
- 51 V
- Continuous Discharge Rate (Normal Use):
- 4096 W
- Maximum Discharge Rate (5 Minutes):
- 5120 W
- Surge Discharge Rate (15 Seconds):
- 6144 W
- Maximum Charge Rate (5 Minutes):
- 5120 W
