JA Solar 570W Mono Traceable PERC Half-Cell MBB LR MC4 Silver Frame
JA Solar 570W Mono Traceable PERC Half-Cell MBB LR MC4 Silver Frame is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Product Features:
- Less levelized cost of energy. A
- Increased power output when partially shaded is due to its multi-busbar configuration. A
- Better mechanical loading tolerance which improves longevity of panel. A
- Lower temperature coefficient ensuring high power output in high temperatures. A
- Comes with a 12-year product warrant and 25-year linear power output warranty. A
Comes supplied with staubli MC4 connectors.
Eco Trade Supplies Solar is an authorized reseller for JA Solar, please refer to the A A in the document section.
Due to size of the panels and A size of the gap between the slats of the pallets (both length and width entries) a fork lift truck on site is required to offload these modules. A
- Supplier Part No:
- JAM72S-30-570-LR-TS-MC4
- Weight:
- 28 kg
- Rated Power:
- 570 W
- MCS Reference:
- BABT 8515-332-565W
- Length:
- 2,333 mm
- Width:
- 1,134 mm
- Depth:
- 30 mm
- VMPP:
- 41.87 V
- IMPP:
- 13.62 A
- Isc:
- 14.37 A
- Voc:
- 50.68 V
- Temp. Coefficient (Mpp):
- -0.35 %
- Clamp position on panel:
- Long side only
- Connector Type:
- MC4
- Efficiency:
- 21.5 %
- Pallet Size:
- Oversized
- Possible Alternatives
- JA Solar 555W Mono PERC Half-Cell GR MC4 with 30mm frame thickness
- A
- JA Solar 565W Mono PERC Half-Cell MBB LR MC4
- Compatible Optimisers
- S1000 Power Optimizer Long Input (1.3m)
- A
- S1000 Power Optimizer Long Input (1.3m) (SolarEdge Promo)
- A
- S1000 Power Optimizer
- A
- S1000 Power Optimizer (SolarEdge Promo)
- A
- SolarEdge S1200 Commercial Power Optimizer Long Input (1.6m)
- A
- SolarEdge S1200 Power Optimizer Long Input (1.6m) (SolarEdge Promo)
- A
- S1200 Power Optimizer
- A
- S1200 Power Optimizer (SolarEdge Promo)
- A
- S1400 Power Optimizer (Long Input 1.8m)
- A
- S1400 Power Optimizer
- A
- Huawei SUN2000 600W Smart PV Optimizer
- A
- Tigo TS4 PV Module Advanced Add-On/Retrofit
